M4222 Indicators
INM4222

M4222 Indicators

Key Highlights & Features

  • 10/100 Base TX with Auto Negotiation
  • DHCP Client
  • Raw bi-directional ports (TCP & UDP)
  • Raw transmit only ports (TCP & UDP)
  • Standard RJ45 connector
  • Standard USB female connector
  • Web Interface

Description

The R400 Series R420 and R423 indicators support Ethernet using the M4222 module, it can be used with application software:
  • K401 Basic Weighing
  • K402 Process control
  • K410 Filling
  • K411 Batching
Connect an R400 indicator onto a network using an Ethernet connection for:
  • Remote monitoring of indicator (for service technicians)
  • Direct connection to the indicator from your PC application using standard sockets interface, to retrieve weight readings and configure settings
  • Remote PC serial port locate your PC away from the indicator and still access the indicator like it was connected directly to the PC on a serial port (M400-525)
Features
  • 10 TCP and 4 UDP bi-directional server sockets to interact with network port on the R400
  • 3 TCP and 4 UDP uni-directional sockets (listening) to interact with auto-output port on the R400
  • Simple configuration of network settings (DHCP, IP, Subnet mask, Gateway, DNS) from the R400 and web interface
  • Ability to access indicator as a serial port on a PC using M400-525
  • DHCP client built in for auto IP negotiation or static IP allocation
